Technical specifications on this page and in the tables
on the following three pages are intended only for rough
preselection.
Gear teeth: Spur gear
Direction
of rotation: Input and output in the same direction
Life time: 20000 h L10h
Permissible
gearbox
temperature
at housing: -10 °C to +80 °C
(deviating temperature ranges
on request)
Lubrication: Oil lubrication
Mounting
position: Any, specify when ordering
Surface
protection: Primer coat RAL 9005 Black
Protection
rating: IP 54
